Brake Pad Back Plates Shot Blasting Machine-HUAYUAN BRAKE MACHINERY CO.,LTD.

Product Introduction

Blast Wheel: Power 7.5kW

Shot Output 210kg/min

Wear Parts Cr20

Blasting Chamber: Manual door

End Disk Diameter Ø650mm

End Disk Spacing 850mm

Rubber Track Sand Leakage Hole Diameter Ø8mm

Shot Circulation System: Lifting Capacity 12T/h

Lifting Power 1.5kW

Shot Cleaning & Separation Capacity 3T/h

Manual Shot Output Adjustment 0–50kg/min

Track Drive System: Track Drive Power 1.5kW

Max Weight per Workpiece ≤8kg

Max Loading Capacity per Batch 75kg

Track Speed 3.4r/min

Dust Removal System: Air Volume 2000m³/h

Power 1.5kW

Dust Emission Concentration ≤10mg/m³

Film-coated Filter Material

Cyclone Filtration Precision (captures 180-mesh fine powder)

Inertial Advection Settling Chamber (integrated in blasting chamber)

Pulse Jet Ash Cleaning Method

Noise Level: 85dB

Product Advantages

01Stable & Reliable, Superior Performance.
02High Quality, Cost-effective Price and Stable Quality.
03Efficiency & Convenience,Ultra-high Precision.
04Timely Response, Worry-free After-Sales Service.
05Advanced Technology, Labor Saving.
06Intelligent Control, Fast Changeover.
07Customized Service, Strong Practicality.
08Environmental Protection and Safety, Ultra-low Energy Consumption.

Scope of Application

01Back plate manufacturing equipment.
02Automatic brake pad production line machine.
03Automatic brake pad making machine.
04Complete brake pad back plate production line.
05Disc brake pad producing machinery.
06Disc brake pad manufacturering equipment.
07Motorcycle brake back plate processing equipment.
08Brake pad steel backing plate manufacturer.
