Car Brake Shoes Outer Arc Grinding Machine

  • Product Introduction:

    The P.V. brake shoe outer arc grinding machine is a special equipment designed for outer arc processing of P.V. brake shoe.

  • Advantages:
    It has the features of simple operation, high processing precision, good surface quality, and high efficiency etc, which is currently the main machine for brake shoe production.

Product Introduction

Grinding wheel:Ø300×230mm Motor：11kw-4 Speed：1440r/min

Fixture drive Motor:110 stepping motor Reducer：rmv-63

Processing range Product width：180-220mm Inner arc of product: R150-R250mm

Overall dimensions:1400×1000×1500mm

Weight:1000kg

Car Brake Shoes Outer Arc Grinding Machine

Product Advantages

  • 01Stable & Reliable, Superior Performance.
  • 02High Quality, Cost-effective Price and Stable Quality.
  • 03Efficiency & Convenience,Ultra-high Precision.
  • 04Timely Response, Worry-free After-Sales Service.
  • 05Advanced Technology, Labor Saving.
  • 06Intelligent Control, Fast Changeover.
  • 07Customized Service, Strong Practicality.
  • 08Environmental Protection and Safety, Ultra-low Energy Consumption.

Scope of Application

  • 01Automobile brake shoe production line machine.
  • 02Automatic brake shoe making machine.
  • 03Automatic brake shoe manufacturing equipment.
  • 04Automatic brake shoe manufacturing process.
  • 05CNC brake shoe producing machine.
  • 06Automatic brake shoe manufacturing factory.
  • 07Drum brake shoe processing machine.
  • 08Producing machines for P.V. brake shoe.
